Test your knowledge about Airport Engineering by taking this Multi Choice Question (MCQ) quiz. Get your score and actual answers at the end of this quiz.
1. As per ICAO recommendation, minimum width of safety area for instrumental runway should be
78 m
150 m
300 m
450 m
2. As per ICAO, for A, B, and C type of airports, maximum effective, transverse and longitudinal grades in percentage respectively are
1.0, 1.5 and 1.5
1.0, 1.5 and 2.0
1.5, 1.5 and 2.0
2.0, 2.0 and 2.0
3. As per ICAO recommendation, the rate of change of longitudinal gradient per 30 m length of vertical curve for A and B type of airports is limited to a maximum of
0.10%
0.20%
0.30%
0.40%
4. Assertion A : The ratio of arriving and departing aircrafts influences the airport capacity:
Reason R :Landing operation is generally given priority over the taking off operation.
Select your answer based on the coding system given below:
Reason R :Landing operation is generally given priority over the taking off operation.
Select your answer based on the coding system given below:
Both A and R are true and R is the correct explanation of A
Both A and R are true and R is not the correct explanation of A
A is true but R is false.
A is false but R is true.
5. An airport has 4 gates. If the weighted average gate occupancy time is 30 minutes and gate utilisation factor is 0.5, then the capacity of the gate will be
1 aircraft per hour
2 aircrafts per hour
4 aircrafts per hour
16 aircrafts per hour
6. The capacity of parallel runway pattern depends upon
weather conditions and navigational aids available
lateral spacing between two runways and weather conditions
lateral spacing between two runways and navigational aids available
lateral spacing between two runways, weather conditions and navigational aids available.
7. The engine failure case for determining the basic runway length may require
only clearway
only stop way
either a clearway or a stopway
either a clearway or a stopway or both
8. The minimum width of clearway is
50 m
100 m
150 m
250 m
9. If the monthly mean of average daily temperature for the hottest month of the year is 25? C and the monthly mean of the maximum daily temperature of the same month of the year is 46? C, the airport reference temperature is
32?C
35.5?C
48?C
25?C
10. Consider the following statements regarding iCAO recommendation for correction to basic runway length
1. The basic runway length should be increased at the rate of 7 percent per 300 m rise in elevation above the mean sea level.
2. The basic runway length after having been corrected for elevation should be further increased at the rate of 1 percent for every 1?C rise in airport reference temperature above the standard atmospheric temperature at that elevation.
3. The runway length after having been corrected for elevation and temperature should be further increased at the rate of 20% for every 1 percent of effective gradient.
Of these statements
1. The basic runway length should be increased at the rate of 7 percent per 300 m rise in elevation above the mean sea level.
2. The basic runway length after having been corrected for elevation should be further increased at the rate of 1 percent for every 1?C rise in airport reference temperature above the standard atmospheric temperature at that elevation.
3. The runway length after having been corrected for elevation and temperature should be further increased at the rate of 20% for every 1 percent of effective gradient.
Of these statements
1 and 2 are correct
2 and 3 are correct
1 and 3 are correct
1,2 and 3 are correct
11. The total length of a runway is 1000 m. The elevation at distance 0,200 m, 400 m, 600 m, 800 m and 1000 m are 100.0 m, 99.2 m, 101.0 m, 101.8 m, 101.4 m and 101.0 m respectively. The effective gradient of runway will be.
0.10%
0.26%
0.43%
0.65%
12. The length of runway under standard conditions is 2000 m. The elevation of airport site is 300 m. Its reference temperature is 33.05?C. If the runway is to be constructed with an effective gradient of 0.25 percent, the corrected runway length will be
2500 m
2600 m
2700 m
2800 m
13. As per ICAO, the minimum basic runway length for A and E type of airport will be
1500 m and 600 m
2100 m and 750 m
1500 m and 750 m
2100 m and 600 m
14. Zero fuel weight of an aircraft is:
equal to empty operating weight
equal to maximum landing weight
less than empty operating weight
equal to sum of empty operating weight and the maximum pay load.
15. The cruising speed of the aircraft is 500 kmph. If there is a head wind of 50 kmph, then the air speed and ground speed of the aircraft respectively will be
450 kmph and 500 kmph
500 kmph and 450 kmph
450 kmph and 450 kmph
500 kmph and 500 kmph
16. As per ICAO, for airports serving big aircrafts, the crosswind component should not exceed
15 kmph
25 kmph
35 kmph
45 kmph
17. Calm period is the percentage of time during which wind intensity is less than
4.8 kmph
6.4 kmph
8.0 kmph
9.6 kmph
18. For determining the basic runway length, the landing case requires that aircraft should come to a stop within p % of the landing distance. The value of p is
40%
50%
60%
75%
19. According to ICAO, all markings on the runways are
Yellow
White
Black
Red
